How to use the fire extinguisher |
| 1. Pull out the safety pin, hold it away from you and release the locking mechanism. |
| 2. Aim low and target the source of the flame rather then the flame itself. Ensure that you stand at least 1.8 meters away from the fire, make sure that you are not spraying against the wind direction. |
| 3. Squeeze lever evenly , and slowly with the extinguisher in an upright postion. |
| 4. Sweep the nozzle from side to sode, target the source of the flame till either the fire is out or the extinguisher runs dry. |
| |
| 1. Fire from solid (Ordinary Combustion) |
| 2. Fire from liquid (Fiammable Liquid) |
| 3. Fire from gas (Fiammable Gas) |
| |
| 1. Do not use if pressure indicator enters red section. |
| 2. Do not use outside specified temperature range. |
| 3. The extinguisher should be inspected every year, it should be recharged if the indicator of the pressure gauge is under the green sector. |
| 4. The extinguisher should be recharged once be used. It should be tested before recharging. |
| 5. The extinguisher should be put in the place where the air is dry and not corroding. And it mushn't be put on the fire, in the sun, in the rain and be rammed. |
| 6. Test pressure(pt): 28Bar |
| 7. Temperature range: -30℃ to + 60℃ |
